SARATOGA: A 10watts single point source flood light; up to 1400 delivered lm. Available in 20°, 50°, or wall wash optics
Stem options now available; accept upto 3 optical accessories. Snoot and cut-off riser (for undercover lighting) to reduce glare.
This is the small model of the Yosemite.
The remote driver could be placed up to 50FT away. The power on canopy option allow 1 fixture per driver.
DENALI with integral driver: limited to 13watts, 120V only Brigelux LED chips.
Up to 1000 delivered lm.
Only incandescent dimming. Everything is field replaceable.
DENALI with remote driver: 12, 20, or 27W, up to 1900 delivered lm. 15°, 35°, and 60° optics.
*The 12 & 20 watts: Xicato and 27 watts: Bridgelux.
NEW PRODUCT: HUME - Larger version of the DENALI. New side mount knuckle.
No set screws (could be added, TE option) held in place with magnetic internal push pins.
Available in 34W or 36W, up to 3600 delivered lm.
Optic and driver are changeable on-site.
Typical 25°, 40°, 55°, NEW 11° (narrow spot option).
NEW 3500K in 90CRI option.
Dimming options: 0-10V, ELV, INC.
NEW COMMERCIAL STEPLIGHT:
UKAN: Indirect 3”X5”, 10W, 800 delivered lm. 18" above the ground give 20ft spacing and getting 1fc/sqft, 90CRI. This fixture has the same dimming as HUME
Integral driver is an option, installed in the internal sleeve to provide flush mounting in a concrete, brick and wood wall.
The face plate is removable to provide access to the light for tilt adjustment. Available with X3 different face plates .
NEW: AGI2 - in-ground uplight: 120V-277V, similar to HT2, 3000lm, good for 30FT to 40FT flag lighting.
12, 20, or 34W, up to 2000 delivered lm; 15°, 25°, 35°, and 60° optics
18" below grade housing for optimum stability and 12" or 18" above grade housing for optimum output.
Drainage is already integrated into this fixture.
COMING SOON (early August): 3”X9” Direct. Horizontal and vertical mounting with X7 different face plates: Standard frosted lens, node free hooded vertical and horizontal, decor plate ( customization pattern) louver.
In general, standard lead time is 3 weeks and modifications 6 weeks.
